CL-533B-GM

Click For Printable Specification Sheet

HOUSING &
SHROUD
Corrosion resistant cast brass.


FINISH: GM- Gun Metal Natural toning process. GM finish will vary due to artistic process.

Also available in AB-Antique Bronze

 LENS: Frosted and heat resistant tempered flat glass, supplied with extra clear glass lens, linear glass lens, and honey comb louver.

SOCKET: Top grade fixed ceramic bi-pin socket.

LAMP:



12V, T3 halogen, 35W max.

Fixture is compatible with LED lamps. See lamp guide for information.

WIRING: Fixture is prewired with a 5ft 18-2 SPT2-W direct burial cord. Wire connectors are available seperately. Universal wire connector (CX-839), or silicone filled wire nut (CX-854) are availble from Corona Lighting.

GASKET:
Silicone gasket for water tight sealing

KNUCKLE:

Adjustable cast brass knuckle with thumb screw and +" NPT threaded male hub on bottom.

MOUNTING:
Standard injection molded spike with +" NPT threaded female hub.

WARRANTY:
Limited lifetime warranty on fixture housing against manufacturer’s defects.
click to enlarge image
click to enlarge drawing
click for installation sheet
click to enlarge image

Electrical Notes:

  • Fixture can be supplied by a variety of LED lamps, see lamp guide for options.
  • Voltage range with LED lamp is 9-17V
  • Proper greasing and lubrication threaded parts is suggested for installation.
  • Remote 12 Volt transformer is required.
  • See transformers and accessories for variety of options and choices.
